RVKN36240 - TYPE 24 SERVICE CHAMBER

• Steel Pressure Housing and Sturdy Service Housing

• Powder coated with resistance welded air ports, power coated for corrosion resistance

• World Class Diaphragm

• High quality rubber compound

• Resistant to heat and cold; Superior flexibility even at -40 Degrees F

• Step bottom with 12 gauge steel

• Orange Alert & reg; Stroke Indicator, Self-piloting Dust Shield

Specifications:

Available Stroke: 2.25", 57mm

A: 3.8", 97mm

D: 9.1", 231mm

E: 4.75", 120.7mm

J: 10.23"

K: -

T: 90 Degrees

S1: 45 Degrees
